| width | 6.625inch |
| height | 7.125inch |
| application | meter socket |
| standard | type 3R |
| Voltage rating | 100 continuous amper |
| phase | 1 phase |
| frequency rated | 60hz |
| size | 2.25L*6.25W*7.125H |
| Cutout size | no main breaker |
| cable entry | over head |
| terminal | single mechanical |
| insulation | glass polyester |
| mounting | surface mount |
| enclosure | aluminum with powder coat finish |
| bypass type | no bypass |
| number of meter postions | 1 postion |
| equipment ground | triplex ground |
| hub opening | 1 inch hub |
| line side wire range | 12-1 awg |
| load side wire range | 12-1 awg |
| QTY/CTN: | 1pcs/ctn |
